Individual hose record
4713487 Hose Repair Specifications
Excavator · Hitachi · ZX470LC-6 · Control Valve
Finished length380 mm
Locate this hose
Installation diagram — Pipe No. 20
Locate Pipe No. 20 in the diagram, then confirm part number 4713487 before removing the hose.
Repair specifications
- Part number
- 4713487
- Diagram pipe number
- 20
- Installation route
- 分配阀右~分配阀后
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 380 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
