Individual hose record
KHJ2342 Hose Repair Specifications
Excavator · Case · CX90D · Control Lever
Finished length380 mm
Locate this hose
Installation diagram — Pipe No. A7-K44
Locate Pipe No. A7-K44 in the diagram, then confirm part number KHJ2342 before removing the hose.
Repair specifications
- Part number
- KHJ2342
- Diagram pipe number
- A7-K44
- Installation route
- 中转接头~缓冲阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 380 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
