Individual hose record
4713504 Hose Repair Specifications
Excavator · Hitachi · ZX470LC-5B · Solenoid Valve
Finished length350 mm
Locate this hose
Installation diagram — Pipe No. 23
Locate Pipe No. 23 in the diagram, then confirm part number 4713504 before removing the hose.
Repair specifications
- Part number
- 4713504
- Diagram pipe number
- 23
- Installation route
- 电磁阀~中转接头
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 350 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 1
