Individual hose record
730501006208 Hose Repair Specifications
Excavator · Sunward · SWE210 · Control Lever
Finished length1,410 mm
Locate this hose
Installation diagram — Pipe No. 63
Locate Pipe No. 63 in the diagram, then confirm part number 730501006208 before removing the hose.
Repair specifications
- Part number
- 730501006208
- Diagram pipe number
- 63
- Installation route
- Intermediate adapter → control valveOriginal Chinese: 中转接头~分配阀
- Hose specification
- DN8;1SN-05;22.5MPa
- Finished length
- 1,410 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 公制内螺纹24°锥带O形圈-轻型
- Right fitting
- 公制内螺纹24°锥带O形圈-轻型
- Quantity
- 1
