Individual hose record
4441179 Hose Repair Specifications
Excavator · Hitachi · ZX120 · Hydraulic Tank
Finished length3,400 mm
Locate this hose
Installation diagram — Pipe No. 17A
Locate Pipe No. 17A in the diagram, then confirm part number 4441179 before removing the hose.
Repair specifications
- Part number
- 4441179
- Diagram pipe number
- 17A
- Installation route
- 液压油箱~进回油阀
- Hose specification
- DN10;1层纤维-6;14MPa
- Finished length
- 3,400 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
