- Length
- 1,450 mm
- Specification
- DN10;1SN-6;7Mpa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 45°美制内螺纹37°内锥
Individual hose record
4643665 Hose Repair Specifications
Excavator · Hitachi · ZX160LC-3 · Hydraulic Pump
Finished length1,450 mm
Locate this hose
Installation diagram — Pipe No. 0
Locate Pipe No. 0 in the diagram, then confirm part number 4643665 before removing the hose.
Repair specifications
- Part number
- 4643665
- Diagram pipe number
- 0
- Installation route
- 液压泵~中转接头
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 1,450 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 45°美制内螺纹37°内锥
- Quantity
- 1
