Individual hose record

4674828 Hose Repair Specifications

Excavator · Hitachi · ZX85USB-3 · Pedal

Finished length450 mm

Locate this hose

Installation diagram — Pipe No. 3

Locate Pipe No. 3 in the diagram, then confirm part number 4674828 before removing the hose.

Hitachi ZX85USB-3 installation diagram showing hydraulic hose 4674828 at Pipe No. 3 — Hitachi ZX85USB-3Part 4674828 · Pipe No. 3Open full-size diagram

Repair specifications

Part number: 4674828
Diagram pipe number: 3
Installation route: 行走推杆~进回油阀
Hose specification: DN6;1SN-4;7Mpa
Finished length: 450 mm
Working pressure: 7 MPa
Left fitting: 美制内螺纹37°内锥
Right fitting: 美制内螺纹37°内锥
Quantity: 1
