Individual hose record
4304411 Hose Repair Specifications
Excavator · Hitachi · EX300LC-3C · Control Lever
Finished length1,150 mm
Locate this hose
Installation diagram — Pipe No. 32
Locate Pipe No. 32 in the diagram, then confirm part number 4304411 before removing the hose.
Repair specifications
- Part number
- 4304411
- Diagram pipe number
- 32
- Installation route
- 左手柄~进回油阀
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 1,150 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
