Individual hose record

730502007630 Hose Repair Specifications

Excavator · Sunward · SWE235E-3H · Attachments – Breaker

Finished length1,550 mm

Locate this hose

Installation diagram — Pipe No. 1

Locate Pipe No. 1 in the diagram, then confirm part number 730502007630 before removing the hose.

Sunward SWE235E-3H installation diagram showing hydraulic hose 730502007630 at Pipe No. 1 — Sunward SWE235E-3HPart 730502007630 · Pipe No. 1Open full-size diagram

Repair specifications

Part number: 730502007630
Diagram pipe number: 1
Installation route: 大臂(破碎器)~过渡阀块(破碎器)
Hose specification: DN25;6SH-16;35MPa
Finished length: 1,550 mm
Working pressure: 35 MPa
Left fitting: Light-series flangeOriginal Chinese: 法兰-轻型
Right fitting: 45°法兰-轻型
Quantity: 1

Same system

Related Hoses

Diagram Pipe No. 8

730502000380

Installation route: 破碎器踏板P~进回油阀AP

Length: 440 mm
Specification: DN6;1SN-04;22.5MPa
Left fitting: 公制内螺纹24°锥带O形圈-轻型
Right fitting: 公制内螺纹24°锥带O形圈-轻型

View full repair specifications
