Individual hose record
161176A1 Hose Repair Specifications
Excavator · Case · CX210N · Control Valve
Finished length450 mm
Locate this hose
Installation diagram — Pipe No. 158
Locate Pipe No. 158 in the diagram, then confirm part number 161176A1 before removing the hose.
Repair specifications
- Part number
- 161176A1
- Diagram pipe number
- 158
- Installation route
- 分配阀前~分配阀前
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 450 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
