Individual hose record
4214424 Hose Repair Specifications
Excavator · Hitachi · EX100WD · Grease Lines
Finished length450 mm
Locate this hose
Installation diagram — Pipe No. 0
Locate Pipe No. 0 in the diagram, then confirm part number 4214424 before removing the hose.
Repair specifications
- Part number
- 4214424
- Diagram pipe number
- 0
- Installation route
- 偏置大臂油缸黄油管
- Hose specification
- DN6;2层纤维-4;14MPa
- Finished length
- 450 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 2
