Individual hose record
4250079 Hose Repair Specifications
Excavator · Hitachi · ZX190W-5N · Swivel Joint
Finished length1,000 mm
Locate this hose
Installation diagram — Pipe No. 1
Locate Pipe No. 1 in the diagram, then confirm part number 4250079 before removing the hose.
Repair specifications
- Part number
- 4250079
- Diagram pipe number
- 1
- Installation route
- 回转接头~铁管(分配阀)
- Hose specification
- DN19;4SP-12;34.5MPa
- Finished length
- 1,000 mm
- Working pressure
- 34.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
