Individual hose record
4701726 Hose Repair Specifications
Excavator · Hitachi · ZX135US-3 · Control Lever
Finished length880 mm
Locate this hose
Installation diagram — Pipe No. 68A
Locate Pipe No. 68A in the diagram, then confirm part number 4701726 before removing the hose.
Repair specifications
- Part number
- 4701726
- Diagram pipe number
- 68A
- Installation route
- 中转接头~过渡阀块(中转接头)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 880 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
