Individual hose record
4664442 Hose Repair Specifications
Excavator · Hitachi · ZX135US-3 · Control Lever
Finished length750 mm
Locate this hose
Installation diagram — Pipe No. 40A
Locate Pipe No. 40A in the diagram, then confirm part number 4664442 before removing the hose.
Repair specifications
- Part number
- 4664442
- Diagram pipe number
- 40A
- Installation route
- 中转接头~分配阀下
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 750 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
