Individual hose record
KHJ2625 Hose Repair Specifications
Excavator · Case · CX75C SR · Control Valve
Finished length2,100 mm
Locate this hose
Installation diagram — Pipe No. B36-D34
Locate Pipe No. B36-D34 in the diagram, then confirm part number KHJ2625 before removing the hose.
Repair specifications
- Part number
- KHJ2625
- Diagram pipe number
- B36-D34
- Installation route
- 分配阀节流阀~液压油箱
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 2,100 mm
- Working pressure
- 18 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
