- Length
- 1,650 mm
- Specification
- DN6;1SN-04;7Mpa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
Individual hose record
4317872 Hose Repair Specifications
Excavator · Hitachi · ZX75US-5N · Attachments – Other Kits
Finished length1,200 mm
Locate this hose
Installation diagram — Pipe No. 15
Locate Pipe No. 15 in the diagram, then confirm part number 4317872 before removing the hose.
Repair specifications
- Part number
- 4317872
- Diagram pipe number
- 15
- Installation route
- 分配阀后~电磁阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 1,200 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 1
Same system
