Individual hose record
KHJ2439 Hose Repair Specifications
Excavator · Case · CX130E · Control Lever
Finished length1,500 mm
Locate this hose
Installation diagram — Pipe No. C48-F28
Locate Pipe No. C48-F28 in the diagram, then confirm part number KHJ2439 before removing the hose.
Repair specifications
- Part number
- KHJ2439
- Diagram pipe number
- C48-F28
- Installation route
- 中转接头~分配阀后
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 1,500 mm
- Working pressure
- 18 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
