Individual hose record
KHJ2054 Hose Repair Specifications
Excavator · Case · CX130E · Control Lever
Finished length1,200 mm
Locate this hose
Installation diagram — Pipe No. 29
Locate Pipe No. 29 in the diagram, then confirm part number KHJ2054 before removing the hose.
Repair specifications
- Part number
- KHJ2054
- Diagram pipe number
- 29
- Installation route
- 推土铲手柄~进回油阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 1,200 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
