Individual hose record
DS2016252 Hose Repair Specifications
Excavator · Doosan · DX140LCR-3 · Boom Assembly
Finished length850 mm
Locate this hose
Installation diagram — Pipe No. 8
Locate Pipe No. 8 in the diagram, then confirm part number DS2016252 before removing the hose.
Repair specifications
- Part number
- DS2016252
- Diagram pipe number
- 8
- Installation route
- Arm cylinder — leftOriginal Chinese: 小臂油缸左
- Hose specification
- DN19;4SH-12;42MPa
- Finished length
- 850 mm
- Working pressure
- 42 MPa
- Left fitting
- Light-series flangeOriginal Chinese: 法兰-轻型
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
