Individual hose record
4367014 Hose Repair Specifications
Excavator · Hitachi · EX550LC-5 · Control Lever
Finished length2,400 mm
Locate this hose
Installation diagram — Pipe No. 1
Locate Pipe No. 1 in the diagram, then confirm part number 4367014 before removing the hose.
Repair specifications
- Part number
- 4367014
- Diagram pipe number
- 1
- Installation route
- 中转接头(手柄)~分配阀下右
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,400 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
