Individual hose record
YA00013151 Hose Repair Specifications
Excavator · Hitachi · ZX350LC-3 · Control Valve
Finished length480 mm
Locate this hose
Installation diagram — Pipe No. 0
Locate Pipe No. 0 in the diagram, then confirm part number YA00013151 before removing the hose.
Repair specifications
- Part number
- YA00013151
- Diagram pipe number
- 0
- Installation route
- 分配阀上~回转马达
- Hose specification
- DN25;1SN-16;8.8MPa
- Finished length
- 480 mm
- Working pressure
- 8.8 MPa
- Left fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Quantity
- 1
