Individual hose record
4269796 Hose Repair Specifications
Excavator · Hitachi · ZX120-3 · Attachments – Breaker
Finished length700 mm
Locate this hose
Installation diagram — Pipe No. 58A
Locate Pipe No. 58A in the diagram, then confirm part number 4269796 before removing the hose.
Repair specifications
- Part number
- 4269796
- Diagram pipe number
- 58A
- Installation route
- 大臂(后段)~卸压安全阀(破碎器)
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 700 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
