Individual hose record
730502004812 Hose Repair Specifications
Excavator · Sunward · SWE25UF-3 · Swing Motor
Finished length900 mm
Locate this hose
Installation diagram — Pipe No. 13
Locate Pipe No. 13 in the diagram, then confirm part number 730502004812 before removing the hose.
Repair specifications
- Part number
- 730502004812
- Diagram pipe number
- 13
- Installation route
- 回转马达~过渡阀块(液压油箱旁)
- Hose specification
- DN10;1SN-06;20.7MPa
- Finished length
- 900 mm
- Working pressure
- 20.7 MPa
- Left fitting
- 公制内螺纹24°锥带O形圈-轻型
- Right fitting
- 90°公制内螺纹24°锥带O形圈-轻型
- Quantity
- 1
