Individual hose record
4334310 Hose Repair Specifications
Excavator · Hitachi · EX160LC-5 · Control Valve
Finished length450 mm
Locate this hose
Installation diagram — Pipe No. 14
Locate Pipe No. 14 in the diagram, then confirm part number 4334310 before removing the hose.
Repair specifications
- Part number
- 4334310
- Diagram pipe number
- 14
- Installation route
- 分配阀前~回转马达
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 450 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
