Individual hose record

4361931 Hose Repair Specifications

Excavator · Hitachi · EX230LC-5 · Hydraulic Pump

Finished length1,500 mm

Locate this hose

Installation diagram — Pipe No. 2

Locate Pipe No. 2 in the diagram, then confirm part number 4361931 before removing the hose.

Hitachi EX230LC-5 installation diagram showing hydraulic hose 4361931 at Pipe No. 2 — Hitachi EX230LC-5Part 4361931 · Pipe No. 2Open full-size diagram

Repair specifications

Part number: 4361931
Diagram pipe number: 2
Installation route: 液压泵~分配阀(进油)
Hose specification: DN22;4SP-14;34.5MPa
Finished length: 1,500 mm
Working pressure: 34.5 MPa
Left fitting: Heavy-series flangeOriginal Chinese: 法兰-重型
Right fitting: 90° heavy-series flangeOriginal Chinese: 90°法兰-重型
Quantity: 1
