Individual hose record
4652698 Hose Repair Specifications
Excavator · Hitachi · ZX650LC-3 · Control Valve
Finished length400 mm
Locate this hose
Installation diagram — Pipe No. 4
Locate Pipe No. 4 in the diagram, then confirm part number 4652698 before removing the hose.
Repair specifications
- Part number
- 4652698
- Diagram pipe number
- 4
- Installation route
- 分配阀下~分配阀左
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 400 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
