Individual hose record
4259804 Hose Repair Specifications
Excavator · Hitachi · EX400LC · Boom Assembly
Finished length2,550 mm
Locate this hose
Installation diagram — Pipe No. 62
Locate Pipe No. 62 in the diagram, then confirm part number 4259804 before removing the hose.
Repair specifications
- Part number
- 4259804
- Diagram pipe number
- 62
- Installation route
- 大臂左1/3/4/5/6
- Hose specification
- DN25;4SP-16;32Mpa
- Finished length
- 2,550 mm
- Working pressure
- 32 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 5
