Individual hose record
4437388 Hose Repair Specifications
Excavator · Hitachi · ZX160LC · Solenoid Valve
Finished length500 mm
Locate this hose
Installation diagram — Pipe No. 40A
Locate Pipe No. 40A in the diagram, then confirm part number 4437388 before removing the hose.
Repair specifications
- Part number
- 4437388
- Diagram pipe number
- 40A
- Installation route
- 电磁阀~中转接头
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 500 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
