Individual hose record
4649212 Hose Repair Specifications
Excavator · Hitachi · ZX135US-6N · Pedal
Finished length2,200 mm
Locate this hose
Installation diagram — Pipe No. 3
Locate Pipe No. 3 in the diagram, then confirm part number 4649212 before removing the hose.
Repair specifications
- Part number
- 4649212
- Diagram pipe number
- 3
- Installation route
- 中转接头~接线板(踏板)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,200 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
