Individual hose record
4471897 Hose Repair Specifications
Excavator · Hitachi · ZX75US · Attachments
Finished length2,000 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 4471897 before removing the hose.
Repair specifications
- Part number
- 4471897
- Diagram pipe number
- 2
- Installation route
- 推土铲手柄~分配阀前
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 2,000 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
