Individual hose record
4247349 Hose Repair Specifications
Excavator · Hitachi · EX400LC · Attachments – Lock Valve
Finished length8,300 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 4247349 before removing the hose.
Repair specifications
- Part number
- 4247349
- Diagram pipe number
- 2
- Installation route
- 小臂油缸锁止阀~分配阀上左
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 8,300 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
