Individual hose record
4384368 Hose Repair Specifications
Excavator · Hitachi · EX160LC-5 · Control Lever
Finished length400 mm
Locate this hose
Installation diagram — Pipe No. 2A
Locate Pipe No. 2A in the diagram, then confirm part number 4384368 before removing the hose.
Repair specifications
- Part number
- 4384368
- Diagram pipe number
- 2A
- Installation route
- 模式转换阀~接线板(中转接头)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 400 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
