4278855 Hose Repair Specifications

Excavator · Hitachi · EX700 · Boom Assembly

Finished length2,550 mm

Locate this hose

Installation diagram — Pipe No. 0

Locate Pipe No. 0 in the diagram, then confirm part number 4278855 before removing the hose.

Hitachi EX700 installation diagram showing hydraulic hose 4278855 at Pipe No. 0 — Hitachi EX700Part 4278855 · Pipe No. 0Open full-size diagram

Repair specifications

Part number: 4278855
Diagram pipe number: 0
Installation route: 大臂左1/2/3/4/7/8/9/10
Hose specification: DN32;6SP-20;31MPa
Finished length: 2,550 mm
Working pressure: 31 MPa
Left fitting: Heavy-series flangeOriginal Chinese: 法兰-重型
Right fitting: Heavy-series flangeOriginal Chinese: 法兰-重型
Quantity: 8
