Individual hose record
4683496 Hose Repair Specifications
Excavator · Hitachi · ZX135US-3 · Attachments
Finished length800 mm
Locate this hose
Installation diagram — Pipe No. 24A
Locate Pipe No. 24A in the diagram, then confirm part number 4683496 before removing the hose.
Repair specifications
- Part number
- 4683496
- Diagram pipe number
- 24A
- Installation route
- 大臂(辅助)~接线板(大臂下)
- Hose specification
- DN10;2SN-6;27.5MPa
- Finished length
- 800 mm
- Working pressure
- 27.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
