Individual hose record
4366749 Hose Repair Specifications
Excavator · Hitachi · EX550LC · Pedal
Finished length560 mm
Locate this hose
Installation diagram — Pipe No. 29
Locate Pipe No. 29 in the diagram, then confirm part number 4366749 before removing the hose.
Repair specifications
- Part number
- 4366749
- Diagram pipe number
- 29
- Installation route
- 中转接头(行走踏板)~过渡阀块(行走踏板)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 560 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
