Individual hose record
4640245 Hose Repair Specifications
Excavator · Hitachi · ZX135US-3 · Attachments – Breaker
Finished length3,350 mm
Locate this hose
Installation diagram — Pipe No. 51A
Locate Pipe No. 51A in the diagram, then confirm part number 4640245 before removing the hose.
Repair specifications
- Part number
- 4640245
- Diagram pipe number
- 51A
- Installation route
- 电磁阀(破碎器)~过渡阀块(隔板)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 3,350 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
