Individual hose record
KRJ10850 Hose Repair Specifications
Excavator · Case · CX230B · Boom Assembly
Finished length1,240 mm
Locate this hose
Installation diagram — Pipe No. 11
Locate Pipe No. 11 in the diagram, then confirm part number KRJ10850 before removing the hose.
Repair specifications
- Part number
- KRJ10850
- Diagram pipe number
- 11
- Installation route
- 大臂左2
- Hose specification
- DN19;4SP-12;35MPa
- Finished length
- 1,240 mm
- Working pressure
- 35 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° light-series flangeOriginal Chinese: 90°法兰-轻型
- Quantity
- 1
