Individual hose record
KHJ2394 Hose Repair Specifications
Excavator · Case · CX145D SR 2PB · Grease Lines
Finished length550 mm
Locate this hose
Installation diagram — Pipe No. 23
Locate Pipe No. 23 in the diagram, then confirm part number KHJ2394 before removing the hose.
Repair specifications
- Part number
- KHJ2394
- Diagram pipe number
- 23
- Installation route
- 分节大臂油缸黄油管
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 550 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
