Individual hose record
2184-1060D53 Hose Repair Specifications
Excavator · Doosan · DX80R · Attachments – Quick Coupler
Finished length1,200 mm
Locate this hose
Installation diagram — Pipe No. 6
Locate Pipe No. 6 in the diagram, then confirm part number 2184-1060D53 before removing the hose.
Repair specifications
- Part number
- 2184-1060D53
- Diagram pipe number
- 6
- Installation route
- 大臂(中前段)~大臂(中后段)
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 1,200 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 45° elbow, British female thread, 60° external cone seatOriginal Chinese: 45°英制内螺纹60°外锥
- Quantity
- 1
