Individual hose record
4680197 Hose Repair Specifications
Excavator · Hitachi · ZX120-3 · Attachments
Finished length2,500 mm
Locate this hose
Installation diagram — Pipe No. 9A
Locate Pipe No. 9A in the diagram, then confirm part number 4680197 before removing the hose.
Repair specifications
- Part number
- 4680197
- Diagram pipe number
- 9A
- Installation route
- 大臂(分节大臂)~控制阀(分节大臂)
- Hose specification
- DN16;4SP-10;34.5Mpa
- Finished length
- 2,500 mm
- Working pressure
- 34.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Quantity
- 1
