Individual hose record
2184-1026D358 Hose Repair Specifications
Excavator · Doosan · DX160LC · Swing Motor
Finished length600 mm
Locate this hose
Installation diagram — Pipe No. 46
Locate Pipe No. 46 in the diagram, then confirm part number 2184-1026D358 before removing the hose.
Repair specifications
- Part number
- 2184-1026D358
- Diagram pipe number
- 46
- Installation route
- 回转马达DB口~回油铁管(液压油箱)
- Hose specification
- DN13;1SN-08;16MPa
- Finished length
- 600 mm
- Working pressure
- 16 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
