Individual hose record
4679983 Hose Repair Specifications
Excavator · Hitachi · ZX220W-3 · Attachments
Finished length3,250 mm
Locate this hose
Installation diagram — Pipe No. 28A
Locate Pipe No. 28A in the diagram, then confirm part number 4679983 before removing the hose.
Repair specifications
- Part number
- 4679983
- Diagram pipe number
- 28A
- Installation route
- 大臂(辅助)~控制阀(辅助)
- Hose specification
- DN10;2SN-6;34.5MPa
- Finished length
- 3,250 mm
- Working pressure
- 34.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
