Individual hose record
9155424 Hose Repair Specifications
Excavator · Hitachi · EX270LC-5 · Solenoid Valve
Finished length1,900 mm
Locate this hose
Installation diagram — Pipe No. 30
Locate Pipe No. 30 in the diagram, then confirm part number 9155424 before removing the hose.
Repair specifications
- Part number
- 9155424
- Diagram pipe number
- 30
- Installation route
- 电磁阀~先导滤芯
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 1,900 mm
- Working pressure
- 18 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
