Individual hose record
4448853 Hose Repair Specifications
Excavator · Hitachi · ZX270LC · Attachments
Finished length1,050 mm
Locate this hose
Installation diagram — Pipe No. 8
Locate Pipe No. 8 in the diagram, then confirm part number 4448853 before removing the hose.
Repair specifications
- Part number
- 4448853
- Diagram pipe number
- 8
- Installation route
- 分配阀左~电磁阀
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 1,050 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
