Individual hose record
4454665 Hose Repair Specifications
Excavator · Hitachi · ZX850LC-3 · Boom Assembly
Finished length2,700 mm
Locate this hose
Installation diagram — Pipe No. 1
Locate Pipe No. 1 in the diagram, then confirm part number 4454665 before removing the hose.
Repair specifications
- Part number
- 4454665
- Diagram pipe number
- 1
- Installation route
- 大臂左1/左2
- Hose specification
- DN32;6SP-20;34.5MPa
- Finished length
- 2,700 mm
- Working pressure
- 34.5 MPa
- Left fitting
- Heavy-series flangeOriginal Chinese: 法兰-重型
- Right fitting
- Heavy-series flangeOriginal Chinese: 法兰-重型
- Quantity
- 2
