Individual hose record
DS20551379 Hose Repair Specifications
Excavator · Doosan · DX55 · Attachments – Quick Coupler
Finished length800 mm
Locate this hose
Installation diagram — Pipe No. 3
Locate Pipe No. 3 in the diagram, then confirm part number DS20551379 before removing the hose.
Repair specifications
- Part number
- DS20551379
- Diagram pipe number
- 3
- Installation route
- 大臂(快换)~小臂(快换)
- Hose specification
- 35MPa
- Finished length
- 800 mm
- Working pressure
- 35 MPa
- Left fitting
- Female threadOriginal Chinese: 内螺纹
- Right fitting
- 90° elbow, female threadOriginal Chinese: 90°内螺纹
- Quantity
- 2
