Individual hose record
4446905 Hose Repair Specifications
Excavator · Hitachi · ZX245USLC-5N · Swivel Joint
Finished length850 mm
Locate this hose
Installation diagram — Pipe No. 4
Locate Pipe No. 4 in the diagram, then confirm part number 4446905 before removing the hose.
Repair specifications
- Part number
- 4446905
- Diagram pipe number
- 4
- Installation route
- 回转接头~回油铁管(液压油箱)
- Hose specification
- DN13;2SN-08;27.5MPa
- Finished length
- 850 mm
- Working pressure
- 27.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
