4710438 Hose Repair Specifications

Excavator · Hitachi · ZX870LC-6 · Attachments

Finished length420 mm

Locate this hose

Installation diagram — Pipe No. 12

Locate Pipe No. 12 in the diagram, then confirm part number 4710438 before removing the hose.

Hitachi ZX870LC-6 installation diagram showing hydraulic hose 4710438 at Pipe No. 12
Hitachi ZX870LC-6Part 4710438 · Pipe No. 12Open full-size diagram

Repair specifications

Part number
4710438
Diagram pipe number
12
Installation route
配重自卸手柄~过渡阀块(配重自卸)
Hose specification
DN10;1SN-06;18MPa
Finished length
420 mm
Working pressure
18 MPa
Left fitting
美制内螺纹74°内锥
Right fitting
美制内螺纹74°内锥
Quantity
1

Same system

Related Hoses

Diagram Pipe No. 48

4285797

Installation route: 过渡阀块(配重自卸)~铁管(配重自卸)

Length
650 mm
Specification
DN12;4SP-8;34.5Mpa
Left fitting
American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
Right fitting
American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
