Individual hose record
4197711 Hose Repair Specifications
Excavator · Hitachi · EX300LC · Boom Assembly
Finished length1,300 mm
Locate this hose
Installation diagram — Pipe No. 12
Locate Pipe No. 12 in the diagram, then confirm part number 4197711 before removing the hose.
Repair specifications
- Part number
- 4197711
- Diagram pipe number
- 12
- Installation route
- Bucket cylinderOriginal Chinese: 铲斗油缸
- Hose specification
- DN25;4SP-16;32Mpa
- Finished length
- 1,300 mm
- Working pressure
- 32 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 2
