Individual hose record
4371505 Hose Repair Specifications
Excavator · Hitachi · EX200LC-5 · Hydraulic Pump
Finished length2,400 mm
Locate this hose
Installation diagram — Pipe No. 15A
Locate Pipe No. 15A in the diagram, then confirm part number 4371505 before removing the hose.
Repair specifications
- Part number
- 4371505
- Diagram pipe number
- 15A
- Installation route
- 液压泵~电磁阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 2,400 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
